VW Comfort Control & Central Electronics Module (J519 / J393) Cloning & Key Programming — Mail-In Bench Service
Passat B6 or CC dead in the driveway after the footwell flooded — no crank, no central locking, and a used comfort module the car refuses? Mail us the original plus a matched donor and we clone the immobilizer, coding, and key data across on the bench, or program a key straight from the module for all-keys-lost.
Sending several modules? Add them all — one box, one return-shipping charge.
VW J519 central electronics and J393 comfort control modules — Passat B6 (2006-2010), Passat CC / CC (2009-2017), Golf Mk5 / Mk6, Jetta (2005-2014), Eos, Tiguan, Touran. Clone-to-donor or key programming. Verified by VIN + module label before you ship.
How It Works
Three simple steps. Hundreds of mail-in jobs completed for shops, locksmiths, and DIY pros.
Pay & Get Address
Click "Order Now", pay securely online. We email shipping address + instructions within minutes.
Ship Your Module
Pack per the instructions and ship to Arlington. USPS goes to our PO Box; UPS and FedEx must use the street address. Customer pays shipping to us.
Receive in 1-2 Days
Work completed within 24 hours of receipt. Ships back next business day at the return speed you chose at checkout — standard to overnight. Tracking emailed.
What You Get
- Your original module's immobilizer participation, component protection, coding, and key data cloned onto the donor, where the original reads
- Or a working key programmed from your module on the bench for all-keys-lost, with the factory immobilizer left intact
- Donor part-number and hardware/software index compatibility verified by VIN and module label before you ship
- Bench read plus verification of both units before anything is written
- Corrosion assessment on water-damaged boards, and an honest call if the original will not read
- Bench communication test on a stable, regulated power supply before return
- Modules returned with tracking — return-shipping speed your choice at checkout
Compatibility
Confirm your part matches one of the variants below before ordering. Not sure? Text us a photo and we'll verify.
Service paths ($250 flat)
Modules covered
Passat B6 & CC — the immobilizer cars
Other common applications
Best for
Will This Fix My Problem?
Honest answer: here's exactly what this service fixes — and what it doesn't.
Fixes:
- ✓Used comfort or central electronics module installed and the car cranks but will not start
- ✓All keys lost on a Passat B6 or CC, where the immobilizer lives in the comfort module
- ✓Water intrusion under the driver's footwell or through the plenum drains killed the module
- ✓Central locking, one-touch windows, interior lighting, or wipers dead or behaving randomly
- ✓No communication with the comfort or central electronics module on a scan tool
- ✓A second-hand module that needs to be made plug-and-play for your exact car
Won't fix:
- ✗Does not include the donor module — you source a matching used unit and we verify the part number first
- ✗Does not clone an original that is internally dead or will not read — that becomes a data-recovery job, see our ECU advanced recovery service
- ✗Does not cover cluster-based immobilizer systems on other VAG cars — see our VW/Audi cluster clone service
- ✗Does not remove or bypass the factory immobilizer — that is our separate VW/Audi immo delete and VIN programming service
- ✗Does not cover the newer VAG BCM2 architecture — see our VW/Audi BCM2 clone service
- ✗Does not repair the wiring, connectors, ground points, or water leak that killed the module in the first place
- ✗Does not bypass proof of ownership
Passat B6 and CC: the immobilizer is in the COMFORT module, not the cluster
On most VAG cars of this era the immobilizer lives in the instrument cluster, which is why our VW/Audi cluster clone service exists. The Passat B6 and CC are the exception: the comfort module carries immobilizer participation and key authorization, so all-keys-lost on those cars is a comfort-module job and the cluster service will not help you. It is also the platform where the module sits low enough to drown — blocked plenum drains push water into the driver's footwell, and the first symptoms are central locking and lighting faults, then a no-start. Clone it while it still reads. Proof of ownership is required.
Shipping Instructions
These details are also emailed to you the moment your payment clears.
Verify first: text or email us your VIN plus clear photos of your original module's label and the donor's label — a technician confirms the part numbers and hardware/software index are a compatible match, and confirms whether your car carries its immobilizer in the comfort module, before you ship. Then send both units for a clone, or the module alone for key programming, to PO Box 120241, Arlington TX 76012 if you ship USPS — or 1009 Oakwood Ln # 120241, Arlington TX 76012 if you ship UPS or FedEx (UPS and FedEx cannot deliver to a PO Box). We clone or program on the bench, test communication, and ship everything back via the return option you pick at checkout (Standard $24.95, UPS 2-Day $54.95, or UPS overnight $94.95).
What to include in your box
- Your original comfort or central electronics module (this is the clone path) AND the donor module
- Key-programming jobs: the module alone, plus any key or key blade a technician asks for
- Year, make, model, and engine (for example 2008 VW Passat B6 2.0T)
- VIN of the vehicle
- VW part number and hardware/software index off BOTH module labels — we pre-verify the match
- What is wrong now: water damage, no-crank, all keys lost, used module rejected, central locking dead
- Proof of ownership (title, registration, or bill of sale) — required for all immobilizer and key work
- Your name, return address, and a phone number or email we can reach you at
Ship to
Auto Module Lab
If shipping USPS
PO Box 120241
Arlington, TX 76012
If shipping UPS or FedEx
1009 Oakwood Ln # 120241
Arlington, TX 76012
Both shipping labels — to the lab and back to you — are purchased the moment you order. Your prepaid inbound label (already addressed) arrives by email; the return ships on the speed you chose at checkout.
Need to perform this job remotely?
Get an Auto Module Lab Remote Programming Kit and have our technicians program supported vehicles from your shop — the car stays on your lift and nothing gets posted.
Buy the interface once — program with us anytime. Supported procedures vary by vehicle, module, OEM software and security requirements.
Frequently Asked
Still have a question? Text us — replies in minutes.
Which module is this, and where does it live in the car?
My Passat B6 lost all its keys. Is this the right service, or the cluster one?
Why won't a used comfort module just work when I plug it in?
The footwell flooded. Can you still save the data?
Do you supply the donor module?
Does the immobilizer stay active after the work?
My car is newer and uses BCM2 — does this listing cover it?
How much is it and how does the mail-in work?
