ABS & traction light fix — by mail

2010–2017 Chevy Equinox / GMC Terrain ABS Module Repair

We repair your own module by mail at our Arlington, TX workshop.

$499 flatAbout 1 week on the benchFlat-rate return shippingFree prepaid label to ship it in

Repair your own module: $499 flat; Keeps its coding; 1-year warranty; return shipping from $29.95
If it is beyond repair: $1,050 total; What you already paid is credited, and you approve before anything is ordered
Dealer replacement: $710–$1,342 installed; RepairPal estimates by model year, October 2026 · RepairPal

1-year repair warranty
or 4 interest-free payments of $124.75 with Afterpay
Decline the board? Your $499 refunded, minus shipping
Certified · 15+ years ECU + module programming

Second-generation Equinox and first-generation Terrain (2.4L, 3.0L and 3.6L), one shared GM electronic brake control module

2010–2017 Chevy Equinox, shown for the Equinox and GMC Terrain — mail-in ABS module repair

Quick Answer

On a 2010–2017 Chevy Equinox or GMC Terrain, the ABS and traction lights with a Service StabiliTrak message and code C0110, C0550 or U0121 usually point to the electronic brake control module, but GM's bulletin PIT5427B says the same warnings can come from a corroded X411 connector under the rear of the vehicle, so check that connector first. We repair your own module on the bench for $499 flat, so it keeps its VIN and calibration and goes back in plug-and-play in most cases. If the processor or board is beyond repair, a replacement board with data transfer and programming is $1,050 in total, with what you paid credited, and nothing is ordered until you approve. Ship the module to our Arlington TX workshop; the repair takes about a week on the bench (2–3 business days with rush repair), then it ships back with tracking.

2010–2017 Chevy Equinox / GMC Terrain: what we see on the bench

From our bench

One Equinox is in our queue right now: a 2012 Equinox 2LT with the 2.4L, ordered October 3, 2026. The module arrived October 7 and is running a little past our usual week, which we told the owner by text on October 16. It is still in progress, so there is no result to report yet.

How common it is

ECU Testing, a UK module-rebuild specialist, calls ABS pump-and-module failure on the Chevy Equinox very common. GM has issued bulletins on these models too, PIT5400 in 2015 and PIT5427B in 2018, for ABS and traction warnings that can come from a corroded X411 connector rather than the module. ECU Testing: Chevrolet Equinox ABS rebuild

The Equinox and Terrain use the same GM service kits: 25926937 for 2010, 20837392 for 2011 and 22754644 for 2012–2017, across the 2.4L, 3.0L and 3.6L. The label on your module often shows a hardware number instead (ECU Testing lists 22755615 on 2010–2012 units and 22804954 on 2012–2017 units, for example), so read your own label before ordering anything.

How It Works

Three steps — your own module, by mail.

Illustration: an ABS control module with its solenoid coil sockets facing up on a bench mat

Pay & Get Address

Click "Order Now", pay securely online. We email shipping address + instructions within minutes.

Illustration: a control module in an anti-static bag inside a shipping box

Ship Your Module

Pack per the instructions and ship to Arlington. USPS goes to our PO Box; UPS and FedEx must use the street address. Your prepaid inbound label arrives by email — shipping to us costs you nothing.

Illustration: an opened ABS control module under a magnifier lamp

Get It Back

The repair takes about a week on the bench (2–3 business days with rush repair) after your module arrives. Ships back at the return speed you chose at checkout — standard to overnight. Tracking emailed.

The 2010–2017 Chevy Equinox / GMC Terrain ABS codes, and what they usually mean

Seeing one of these on your scan tool? Here's what it usually points to on this vehicle.

C0110

Pump motor circuit malfunction

The pump-motor driver inside the module, or the pump motor itself

C0550

Electronic control unit performance

A fault inside the module itself

U0121

Lost communication with the ABS module

The module has gone quiet on the network, or its wiring has; GM's X411 bulletin lists this code, so check that connector first

C0035–C0050 (one wheel)

Wheel-speed sensor circuit at that corner

A sensor, tone ring or harness at that wheel, not the module; the two rear codes are also on GM's X411 list

C0186, C0196, C0710

Lateral-acceleration, yaw-rate and steering-position signals

Those sensors and their wiring; all three are also on GM's X411 list

C0800

Module power circuit

Battery voltage, fuses or a ground; it is on GM's X411 list too, so not a module verdict on its own

What it costs to fix a 2010–2017 Chevy Equinox / GMC Terrain ABS module

Every option side by side, with where each price comes from.

Dealer replacement, 2012–2017 Equinox or Terrain

$1,280–$1,342 installed

RepairPal estimate, October 2026; the same for every year 2012–2017 · RepairPal

Dealer replacement, 2010–2011 Equinox or Terrain

$710–$783 installed

RepairPal estimate, October 2026 · RepairPal

New GM module kit 22754644 (2012–2017)

$1,145.46 list

$637.08 online sale price; it must be programmed to your VIN · GM Parts Giant

New GM module kit 25926937 (2010)

$585.62 list

$329.05 online sale price; it must be programmed to your VIN · GM Parts Giant

Repair of your own module at Auto Module Lab

$499 flat

Keeps its coding; 1-year warranty; return shipping from $29.95

Replacement board, if yours is beyond repair

$1,050 total

What you already paid is credited, and you approve before anything is ordered

What You Get

ABS module repaired and bench-tested
Reprogrammed if needed (VIN-coded modules)
Plug-and-play reinstall — no coding required in most cases
About 1 week on the bench after your module arrives — or add rush repair (+$100) for 2–3 business days
Return shipping your choice at checkout — standard, 2-day, or overnight
1-year warranty on the repair — extend to 2 years (+$50), 3 years (+$100) or 5 years (+$150) at checkout

Flat-rate pricing

$499USD

or 4 interest-free payments of $124.75 with Afterpay at checkout

About 1 Week Bench Time (Rush 2–3 Days Available)
Return speed your choice — standard to overnight
Tracking emailed when shipped
1-year repair warranty
Optional extended warranty: 2 years +$50, 3 years +$100, 5 years +$150
Rush repair available: 2–3 business days (+$100)

Turnaround is our bench-time estimate after your module arrives — the repair takes about a week on the bench (2–3 business days with rush repair), but complex damage, parts, or extra testing can extend it. Not a guaranteed completion or delivery date.

We don't diagnose your car. Order once you or your mechanic have confirmed this module is the cause. A clone copies the data already in your module — including earlier work by another shop — and "plug-and-play" isn't a promise the car will start. Not sure? Text us first. Mail-In Service Terms, Section 6.

Sending several modules? Add them all — one box, one return-shipping charge.

The dealer path for this job: a new module, dealer programming, and usually a tow — each billed separately. See the comparison

Secure Square checkout — card, Apple Pay, Google Pay, Cash App Pay, or Afterpay. Shipping address + detailed instructions emailed automatically.

Will This Fix My Problem?

Honest answer: here's exactly what this service fixes — and what it doesn't.

Fixes:

ABS and traction-control lights on at the same time
A Service StabiliTrak, Service ABS or Service Traction Control message on the dash
StabiliTrak and traction control switched off
Code C0110 or C0550 stored in the ABS module
Other modules report lost communication with the ABS module (U0121)

Won't fix:

Wheel speed sensor failures (sensor replacement is on-car work)
Hydraulic pump or valve body mechanical failure (we repair electronics, not pump motors)
Brake line / fluid issues

Before you order

You diagnose, we service the module.
We don't have your car and we don't diagnose it. Order once you or your mechanic have confirmed this module is the cause. If the work is completed and the car still has the same symptom because of another fault, the work is still done — a bench re-test under warranty is free.
A clone copies what is in your module.
We transfer the data as we read it. If another shop or tool already worked on the module — an unfinished clone, a tune, a delete — that data can come across too. Tell us before you ship.
What "plug-and-play" means.
No dealer programming should be needed when your original data is intact, the donor matches your module (same type, hardware and software family) and the rest of the car works. It isn't a promise that the car will start or run.

Not sure it's the module? Text us the codes and a photo of the module label Mail-In Service Terms, Section 6

Shipping Instructions

These details are also emailed to you the moment your payment clears.

What to include in your box

Ship the electronic brake control module, not the hydraulic valve block, unless we ask for the whole unit. GM sells the module as its own kit, separate from the valve block; if you're not sure which part comes off, text us a photo of the module and its label first.
Put your VIN and the part number from the module label in the box.
Unplug the module only with the ignition off, and don't pry it off the valve block.
If only the module comes off and the brake lines stay connected, nothing needs bleeding. If the whole ABS unit comes out, cap the lines and bleed the brakes after it goes back in, with a scan-tool automated bleed if air may have reached the hydraulic unit.
We email you a prepaid label to send it in. Pick standard, 2-day or overnight return at checkout.

Ship to

Auto Module Lab

If shipping USPS

PO Box 120241
Arlington, TX 76012

If shipping UPS or FedEx

1009 Oakwood Ln # 120241
Arlington, TX 76012

Your prepaid inbound label (already addressed) arrives by email the moment you order; the return label is bought when your module reaches the bench and ships on the speed you chose at checkout.

2010–2017 Chevy Equinox / GMC Terrain FAQ

Vehicle-specific answers.

Why are the ABS, traction and StabiliTrak warnings all on at once on my Equinox or Terrain?

All three run off one controller, the electronic brake control module, so when it fails inside they switch off together, often with code C0110, C0550 or U0121. GM also says the same warnings can come from a corroded X411 connector under the rear of the vehicle (bulletin PIT5427B), and a bad wheel-speed sensor can light them too, so read the ABS codes before buying anything.

How much does an Equinox or Terrain ABS module repair cost?

$499 flat to repair your own module, plus return shipping from $29.95. If testing shows the processor or board is beyond repair, a replacement board with data transfer and programming is $1,050 in total, with what you paid credited, and we only order it after you approve. For comparison, RepairPal estimates $1,280 to $1,342 for a dealer replacement on a 2012–2017 Equinox or Terrain.

Will the module need programming after the repair?

In most cases, no. We repair the module that came out of your vehicle, so it keeps its VIN and calibration and goes back in plug-and-play. A new or used replacement is different: it has to go through GM's Electronic Brake Control Module Programming and Setup procedure before it will run the system properly.

Is there a recall on the Equinox or Terrain ABS module?

NHTSA lists no ABS module recall for the 2010–2017 Equinox or Terrain, so the repair is on the owner. GM published service bulletins instead, PIT5400 in 2015 and PIT5427B in 2018, that send technicians to the X411 connector when ABS and traction warnings show up with communication codes. Check your own VIN on NHTSA's recall lookup to be sure.

How long does the repair take?

About a week on the bench (2–3 business days with rush repair) at our Arlington TX workshop, plus shipping each way. Round-trip from anywhere in the US: typically about two weeks. If your module needs the replacement board, we tell you the timing when we quote it.

What exactly do I ship?

The electronic brake control module, with your VIN and the part number from its label. GM sells it as its own kit, separate from the hydraulic valve block, so don't send the valve block unless we ask for it; if you're not sure which part comes off, text us a photo first. We email a prepaid label, so sending it to us costs nothing.
